Products / Power distribution units (PDUs)

Power distribution units (PDUs)

75-95 kVA

isolation transformer and switchgear to suit any topology

Up to Form 4b Type 6

tested

Integrated monitoring

HMI touchscreen, metering, load limit alarms and active temperature monitoring available

Safe. Scalable.
Specified by you.

We can fully customise our power distribution units (PDUs) to your specification requirements. With data centre space at a premium, our PDUs are designed to have the smallest possible footprint while maintaining type test temperature rise characteristics and allowing for termination space.

See specifications

Speak to an engineer

Specifications

Standard

Construction: Modular metal work system construction
Treatment: electro-galvanised steel plate/iron-phosphated steel plate
Finish: RAL 7035 powder lacquered 50-80µm
Short circuit rating: 50kA Icu
Ingress protection: IP3x

Customisations

Flexible units: fixed, withdrawable or plug-in
Flexible access points: cable and busbar
Outgoing cables: arranged at the left, right, rear, top or bottom
Colours: customised to your brand

Get brochure

Speak to an engineer

Benefits

Why choose Capital for PDUs?

Flexible design options

Our system is type tested with components from leading manufacturers. This enables us to offer alternatives to suit availability of these brands in specific geographic locations or client preference.

Proven design process

Our PDUs are carefully designed using Solidworks 3D modelling and EPLAN software. Once approved, production processes and final testing procedures are designed to ensure that any errors in manufacturing are controlled at the earliest possible stage. The uniform quality assurance process keeps builds efficient and streamlined.

Customised skids

Addition of customised skids or housings can help with quicker deployment. We can work with your contractors to include pre-formed containment options to speed up installation work on site.

Installation and commissioning support

Our team of service and commissioning engineers and electricians are familiar with the manufacturing process and have deep knowledge of each product’s construction. They will help with installation and commissioning and ensure a faster move of PDUs to yellow tag.

Get brochure

Speak to an engineer
